Item 18. PBN/ Specifications
(Include as many of the applicable descriptors, up to a maximum of 8 entries (not more than 16 characters).
PBN/
RNAV SPECIFICATIONS
A1
RNAV 10 (RNP 10)
B1
RNAV 5 all permitted sensors
B2
RNAV 5 GNSS
B3
RNAV 5 DME/DME
B4
RNAV 5 VOR/DME
B5
RNAV 5 INS or IRS
B6
RNAV 5 LORAN C
C1
RNAV 2 all permitted sensors
C2
RNAV 2 GNSS
C3
RNAV 2 DME/DME
C4
RNAV 2 DME/DME/IRU
D1
RNAV 1 all permitted sensors
D2
RNAV 1 GNSS
D3
RNAV 1 DME/DME
D4
RNAV 1 DME/DME/IRU
PBN/
RNP SPECIFICATIONS
L1
RNP 4
O1
Basic RNP 1 all permitted sensors
O2
Basic RNP 1 GNSS
O3
Basic RNP 1 DME/DME
O4
Basic RNP 1 DME/DME/IRU
S1
RNP APCH
S2
RNP APCH with BARO
−
VNAV
T1
RNP AR APCH with RF (special
authorization required)
T2
RNP AR APCH without RF (special
authorization required)
NOTE
−
1.
PBN Codes B1
−
B6 indicates RNAV 5 capability. The FAA considers these B codes to be synonymous and qualifying
for point
−
to
−
point routing but not for assignment to the PBN routes shown in the table.
2.
Combinations of alphanumeric characters not included above are reserved.
3.
The PBN/ specifications are allowed per ICAO Doc. 4444. The FAA makes use of a subset of these codes as described
in the section on filing navigation capability.
(c)
The following sections detail what capabilities need to be provided to obtain services from the FAA for
:
IFR flights (general).
Assignment of Performance
−
Based Navigation (PBN) routes.
Automated Departure clearance (via Datacom DCL or PDC).
Reduced Vertical Separation Minima (if requesting FL 290 or above).
Reduced Separation in Oceanic Airspace.
(d)
Capabilities such as voice communications, required communications performance, approach aids, and
ADS
−
C, are not required in a flight plan that remains entirely within domestic airspace.
